| Battery voltage | 12 V |
|---|
| Charge current | 30 A (15 A in NIGHT/LOW mode) |
|---|
| Outputs | 3 |
|---|
| AC input | 110-120 VAC nominal (100-130 VAC, 45-65 Hz) |
|---|
| Ac connection | 1.8 m (6 ft) cable with US NEMA 5-15 plug |
|---|
| Efficiency | 93% |
|---|
| No load power | 0.5 W |
|---|
| Absorption | 14.4 V normal / 14.7 V high / 14.2 V Li-ion |
|---|
| Float | 13.8 V / 13.8 V / 13.5 V |
|---|
| Storage | 13.2 V / 13.2 V / 13.5 V |
|---|
| Algorithm | Adaptive 6-stage; Li-ion mode; can be used as power supply |
|---|
| Battery connection | Screw terminals 16 mm² / AWG6 |
|---|
| Protection | IP22 |
|---|
| Operating temperature | -20 to +50°C (full output to 40°C) |
|---|
| Weight | 1.3 kg |
|---|
| Size (H × W × D) | 245 x 108 x 65 mm |
|---|
| Standards | UL 1236, CSA C22.2, EN 60335-1, EN 60335-2-29 |
|---|
| Bluetooth | Yes; VE.Smart networking |
|---|
